Alltion AM5000 Series Surgical Microscope
Alltion AM5000 Series Surgical Microscope may not be in stock. Please call us for ETA before purchasing.
Couldn't load pickup availability
Warranty Information
Warranty Information
1 Year
Alltion AM5000 Series Surgical Microscope
The Alltion AM5000 Surgical Microscope stands as a paramount tool for dental and medical professionals, offering unparalleled precision, clarity, and versatility. Engineered for mid-level and advanced practitioners, it shines in endodontic treatments and a variety of medical fields including Dental, ENT, General Surgery, and Ophthalmology. The AM5000 is distinguished by its superior German-engineered spring arm and Schott optics, delivering exceptional par-focal performance, expansive field of view, and crisp three-dimensional images.
Key features
- Adjustable binocular with rolling stand mount: Ensures comfortable and precise positioning with an ergonomic design tailored for extended periods of use.
- 6-step magnification: Ranges from a minimum of 3.2X to a maximum of 21X, accommodating diverse procedural requirements with ease.
- Variable objective lens: With a range of 198mm to 455mm, it offers flexible working distances to suit various surgical needs.
- Built-in video camera options: Comes equipped with a SONY HD or an ALLCAM4 4K Video Camera, capturing high-resolution images and videos directly from the surgical field.
- WIFI transmission: Allows for seamless sharing and analysis of surgical images and videos across IOS and Android systems.
- LED lighting modes: Features five LED lighting modes with up to 80,000 LUX, providing brilliant illumination for every procedure.
- Ergonomic and durable construction: Crafted from high-quality steel with cables neatly hidden, ensuring a clutter-free working environment. The microscope body can rotate 360° for comprehensive accessibility.
Top features:
- Flexible Optics Rotating Assembly (FORA): Equipped with a 90° binocular extender and a pendulum rotation device, FORA enables natural posture and angle adjustments without repositioning the entire microscope.
- Fluorescence and white illumination: Offers dual-mode illumination with an automatic anti-violet shield in fluorescence mode, aiding in distinguishing between natural tissues and artificial materials efficiently.
- Integrated 4K camera system: Features photograph, video recording, and freeze modes alongside USB storage, double HDMI output, playback capabilities, and contrasting image functions. The built-in WiFi and mouse operation, along with wireless foot control, streamline the documentation and sharing process.
- Single-handed operation: Designed for convenience and efficiency, the AM5000 allows for effortless adjustments with a multi-function knob.
- High-quality optics: Ensures edge-to-edge clarity, improved contrast, and effective stray light elimination, providing a detailed view of the surgical site.
- Optional accessories: A wide range of accessories, including beam splitters, rotation devices, and additional cameras, can be integrated to enhance the microscope's functionality.
Flexible optics rotating assembly (FORA) pendulum functionality
The FORA comes with a 90° binocular extender, a pendulum rotation device, and a beam splitter with options of 2:8 or 5:5. This allows the operator to maintain a natural and upright posture while observing the patient from a specific angle. Furthermore, the operator can adjust only the direction of the optical pod, while keeping the binocular stationary
Fluorescence and white illumination
The illumination has two modes: white and fluorescence. When switching to fluorescence mode, the light switch knob is connected to an anti-violet shield. This shield automatically moves into the light path, ensuring the operator’s eyes are protected. The fluorescence mode assists in identifying boundaries between natural tooth tissue and artificial materials. Specifically, the AM-5000’s fluorescence mode allows the operator to differentiate between natural hard tooth tissue and dental composite resin material. This clear visual differentiation not only allows the operator to swiftly pinpoint the affected area but also conserves their valuable time during the excavation process.
| Optic | Type | Standard | Optional |
| Magnification | Manual 6-step magnification | ||
| Objective lens | 198-455mm Variable objective lens | Objective lens( 250mm/ 300mm/ 400mm) | |
| Magnification range | 1.4X-22.8X | ||
| Binocular | 0-180' Inclined binocular head with knob of pupillary distance adjustment | 45' Binocular/ straight binocular | |
| Range of interpupillary distance | 50mm-75mm | ||
| Eyepiece | 12.5X/18mm | ||
| Glass technology | Premium quality apochromatic technology | ||
| Diopter | ±7D | ||
| Optical extender | 30' Binocular extender+ beam splitter+ rotation device; 45" /90' binocular extender with angle rotation device | ||
| Illumination | LED | Long-life LED > 50,000 hours | |
| Illumination | Illumination up to 80,000lx with a 250mm fixed focus objective | ||
| Color rendering | > 85% | ||
| Color Temperature | 5500K | ||
| Light spot | Three types of light spot: maximum/ medium/minimum (without filter) Two types of filter: green/ yellow | ||
| Fluorescence mode | Fluorescence mode | ||
| Power supply | Camera | Built-in 4K camera(see the table below for detailed parameters) | |
| Rated Voltage | Input: AC100-240V,50/60 HZ; output: DC12V/3A | ||
| Input Power | 25-S0VA | ||
| Support system | Floor Stand | Fixed floor stand/floor stand with 950 panto aph arm/ceiling mount/ low position wall mount/ high position wall mount/ table mount/table cwamp mount |
